Article 5: Pharmaceutical-Grade Dry Powder Electromagnetic Filter - High Standard Equipment for GMP Certification
Product Advantages:
-
GMP Certification: Complies with international standards like GMP, ISO9001, ISO14001, meeting the stringent hygiene requirements of the pharmaceutical industry.
-
High Cleanliness: Parts in contact with materials are made of 316L stainless steel with a surface roughness of Ra ≤ 0.4 μm.
-
Zero Contamination Risk: Employs a physical adsorption method, adding no chemicals, ensuring material safety.
-
Fully Automatic Control: Equipped with a PLC control system for one-button start/stop and automatic slag discharge, reducing manual intervention.
-
Online Monitoring: Can be equipped with online detection systems for real-time monitoring of iron removal effectiveness, ensuring product quality.
Product Parameter Table:
|
Model
|
Working Bore
|
Magnetic Field Strength
|
Power
|
Processing Capacity
|
Cleanliness Level
|
|
MYGF-250
|
φ250mm
|
3500-14000GS
|
12KW
|
300-800kg/h
|
Class 100
|
|
MYGF-300
|
φ300mm
|
3500-14000GS
|
13KW
|
600-1000kg/h
|
Class 100
|
|
MYGF-350
|
φ350mm
|
3500-14000GS
|
16KW
|
800-1300kg/h
|
Class 100
|
|
MYGF-400
|
φ400mm
|
3500-14000GS
|
20KW
|
1000-1500kg/h
|
Class 100
|
Q&A:
Q: Does the equipment comply with pharmaceutical industry validation requirements?
A: Yes. The equipment design complies with GMP requirements. We can provide IQ/OQ/PQ validation documents to meet pharmaceutical equipment validation standards.
Q: How does the equipment guarantee zero cross-contamination?
A: The equipment has a fully sealed design and is equipped with a CIP cleaning system, allowing for online cleaning and sterilization, effectively preventing cross-contamination.
Q: Does the equipment support data traceability?
A: Yes. The equipment is equipped with a data recording system that can log operating parameters, maintenance records, etc., meeting pharmaceutical industry data integrity requirements.
Application Case:
A pharmaceutical company adopted the DCFJ-350 model for iron removal in pharmaceutical excipients. The equipment operates stably with significant iron removal results, reducing iron content in the material from the original 15 ppm to below 1 ppm. The products fully comply with pharmaceutical industry standards and successfully passed GMP certification.
Company Profile:
Tianjin Minyang Precision Machinery Co., Ltd. is a high-tech enterprise specializing in the research, production, sales, and service of magnetic application equipment. Established in 2019, the company is located in the Balitai Industrial Park, Jinnan District, Tianjin, covering a factory building area of 3,500 square meters, including a 2,700-square-meter production workshop and an 800-square-meter office area. The company holds three major system certifications: ISO9001 Quality Management System, ISO14001 Environmental Management System, and ISO45001 Occupational Health and Safety Management System. It possesses over thirty patents and software copyrights. Adhering to the business philosophy of "Quality, Innovation, Service," the company is committed to providing customers with first-class products and attentive service.
